Type	Stage	Size	Input speed	Ratio	Output speed	Nominal Output Torque	Motor power	Service Factor	Overhung Load	Design

Note : Select required duty cycle

Agitators

Sub-Category	HR < 3	HR Between 3-10	HR above 10
pure liquids	0.8	1	1.25
solids and liquids	1	1.25	1.5
Liquids-variable density	1	1.25	1.5
pure liquids	0.8	1	1.25
solids and liquids	1	1.25	1.5
Liquids-variable density	1	1.25	1.5

Blowers

Sub-Category	HR < 3	HR Between 3-10	HR above 10
centrifugal	0.8	1	1.25
lobe	1	1.25	1.5
vane	0.8	1	1.25
centrifugal	0.8	1	1.25
lobe	1	1.25	1.5
vane	0.8	1	1.25

Brewing and distilling

Sub-Category	HR < 3	HR Between 3-10	HR above 10
bottling machinery	0.8	1	1.25
brew kettles-continuous duty	0.8	1	1.25
Cookers-continuous duty	0.8	1	1.25
mash tubs-continuous duty	0.8	1	1.25
scale hopper-frequent starts	1	1.25	1.5
bottling machinery	0.8	1	1.25
brew kettles-continuous duty	0.8	1	1.25
Cookers-continuous duty	0.8	1	1.25
mash tubs-continuous duty	0.8	1	1.25
scale hopper-frequent starts	1	1.25	1.5

Can filling machine

Sub-Category	HR < 3	HR Between 3-10	HR above 10
Can filling machine	0.8	1	1.25
Can filling machine	0.8	1	1.25

Cane Knives

Sub-Category	HR < 3	HR Between 3-10	HR above 10
Cane Knives	1	1.25	1.5
Cane Knives	1	1.25	1.5

Car dumpers

Sub-Category	HR < 3	HR Between 3-10	HR above 10
Car dumpers	1.5	1.75	2
Car dumpers	1.5	1.75	2

Car pullers

Sub-Category	HR < 3	HR Between 3-10	HR above 10
Car pullers	1	1.25	1.5
Car pullers	1	1.25	1.5

Clarifiers

Sub-Category	HR < 3	HR Between 3-10	HR above 10
Clarifiers	0.8	1	1.25
Clarifiers	0.8	1	1.25

Classifiers

Sub-Category	HR < 3	HR Between 3-10	HR above 10
Classifiers	1	1.25	1.5
Classifiers	1	1.25	1.5

Clay working machinery

Sub-Category	HR < 3	HR Between 3-10	HR above 10
brick press	1.5	1.75	2
briqutte machine	1.5	1.75	2
pug mill	1	1.25	1.5
clay working machinery	1	1.25	1.5
brick press	1.5	1.75	2
briqutte machine	1.5	1.75	2
pug mill	1	1.25	1.5
clay working machinery	1	1.25	1.5

Compressor

Sub-Category	HR < 3	HR Between 3-10	HR above 10
centrifugal	0.8	1	1.25
reciprocating multi-cylinder	1	1.25	1.5
reciprocating single-cylinder	1.5	1.75	2
lobe	1	1.25	1.5
centrifugal	0.8	1	1.25
reciprocating multi-cylinder	1	1.25	1.5
reciprocating single-cylinder	1.5	1.75	2
lobe	1	1.25	1.5

Conveyor-uniformly loaded

Sub-Category	HR < 3	HR Between 3-10	HR above 10
apron	0.8	1	1.25
assembly	0.8	1	1.25
felt stretcher	0.8	1	1.25
bucket	0.8	1	1.25
chain	0.8	1	1.25
flight	0.8	1	1.25
oven	0.8	1	1.25
screw	0.8	1	1.25
apron	0.8	1	1.25
assembly	0.8	1	1.25
felt stretcher	0.8	1	1.25
bucket	0.8	1	1.25
chain	0.8	1	1.25
flight	0.8	1	1.25
oven	0.8	1	1.25
screw	0.8	1	1.25

Conveyor-uniformly fed

Sub-Category	HR < 3	HR Between 3-10	HR above 10
apron	0.8	1	1.25
assembly	0.8	1	1.25
belt	0.8	1	1.25
bucket	0.8	1	1.25
chain	0.8	1	1.25
flight	0.8	1	1.25
oven	0.8	1	1.25
screw	0.8	1	1.25
apron	0.8	1	1.25
assembly	0.8	1	1.25
belt	0.8	1	1.25
bucket	0.8	1	1.25
chain	0.8	1	1.25
flight	0.8	1	1.25
oven	0.8	1	1.25
screw	0.8	1	1.25

Conveyor-heavy duty not uniformly fed

Sub-Category	HR < 3	HR Between 3-10	HR above 10
apron	1	1.25	1.5
assembly	1	1.25	1.5
belt	1	1.25	1.5
bucket	1	1.25	1.5
chain	1	1.25	1.5
flight	1	1.25	1.5
oven	1	1.25	1.5
screw	1	1.25	1.5
live roll	*	*	*
reciprocating	1.5	1.75	2
shaker	1.5	1.75	2
apron	1	1.25	1.5
assembly	1	1.25	1.5
belt	1	1.25	1.5
bucket	1	1.25	1.5
chain	1	1.25	1.5
flight	1	1.25	1.5
oven	1	1.25	1.5
screw	1	1.25	1.5
live roll	*	*	*
reciprocating	1.5	1.75	2
shaker	1.5	1.75	2

cranes

Sub-Category	HR < 3	HR Between 3-10	HR above 10
main hoists	0.8	1	1.25
bridge travel	*	*	*
trolley travel	*	*	*
main hoists	0.8	1	1.25
bridge travel	*	*	*
trolley travel	*	*	*

crusher

Sub-Category	HR < 3	HR Between 3-10	HR above 10
ore	1.5	1.75	2
stone	1.5	1.75	2
sugar	1	1.25	1.5
ore	1.5	1.75	2
stone	1.5	1.75	2
sugar	1	1.25	1.5

Dredges

Sub-Category	HR < 3	HR Between 3-10	HR above 10
cable reels	1	1.25	1.5
conveyors	1	1.25	1.5
cutter head drivers	1.5	1.75	2
jig drivers	1.5	1.75	2
maneuvering winches	1	1.25	1.5
pumps	1	1.25	1.5
screen drive	1.5	1.75	2
stackers	1	1.25	1.5
utility winches	1	1.25	1.5
cable reels	1	1.25	1.5
conveyors	1	1.25	1.5
cutter head drivers	1.5	1.75	2
jig drivers	1.5	1.75	2
maneuvering winches	1	1.25	1.5
pumps	1	1.25	1.5
screen drive	1.5	1.75	2
stackers	1	1.25	1.5
utility winches	1	1.25	1.5

Dry dock cranes

Sub-Category	HR < 3	HR Between 3-10	HR above 10
main hoists	*	*	*
auxillary hoist	*	*	*
boom,luffing	*	*	*
rotating,swing or slew	*	*	*
tracking, drive wheels	*	*	*
main hoists	*	*	*
auxillary hoist	*	*	*
boom,luffing	*	*	*
rotating,swing or slew	*	*	*
tracking, drive wheels	*	*	*

Elevators

Sub-Category	HR < 3	HR Between 3-10	HR above 10
Bucket-uniform load	0.8	1	1.25
Bucket-heavy load	1	1.25	1.5
Bucket-continuous	0.8	1	1.25
escalators	0.8	1	1.25
freight	1	1.25	1.5
gravity discharge	0.8	1	1.25
centrifugal discharge	0.8	1	1.25
man lifts	*	*	*
passenger lifts	*	*	*
Bucket-uniform load	0.8	1	1.25
Bucket-heavy load	1	1.25	1.5
Bucket-continuous	0.8	1	1.25
escalators	0.8	1	1.25
freight	1	1.25	1.5
gravity discharge	0.8	1	1.25
centrifugal discharge	0.8	1	1.25
man lifts	*	*	*
passenger lifts	*	*	*

Fans

Sub-Category	HR < 3	HR Between 3-10	HR above 10
centrifugal	0.8	1	1.25
cooling tower-induced draft	*	*	*
cooling tower-forced draft	*	*	*
induced draft	1	1.25	1.5
large,mini,etc	1	1.25	1.5
large,industrial	1	*	*
light smaller diameter	0.8	1	1.25
centrifugal	0.8	1	1.25
cooling tower-induced draft	*	*	*
cooling tower-forced draft	*	*	*
induced draft	1	1.25	1.5
large,mini,etc	1	1.25	1.5
large,industrial	1	*	*
light smaller diameter	0.8	1	1.25

Feeders

Sub-Category	HR < 3	HR Between 3-10	HR above 10
apron	1	1.25	1.5
belt	1	1.25	1.5
disc	0.8	1	1.25
reciprocating	1.5	1.75	2
screw	1	1.25	1.5
apron	1	1.25	1.5
belt	1	1.25	1.5
disc	0.8	1	1.25
reciprocating	1.5	1.75	2
screw	1	1.25	1.5

Food industry

Sub-Category	HR < 3	HR Between 3-10	HR above 10
beef slicer	1	1.25	1.5
cereal cooker	0.8	1	1.25
dough mixer	1	1.25	1.5
meat grinders	1	1.25	1.5
beef slicer	1	1.25	1.5
cereal cooker	0.8	1	1.25
dough mixer	1	1.25	1.5
meat grinders	1	1.25	1.5

Generators-hot welding

Sub-Category	HR < 3	HR Between 3-10	HR above 10
Generators-hot welding	0.8	1	1.25
Generators-hot welding	0.8	1	1.25

Hammer mills

Sub-Category	HR < 3	HR Between 3-10	HR above 10
Hammer mills	1.5	1.75	2
Hammer mills	1.5	1.75	2

Hoists

Sub-Category	HR < 3	HR Between 3-10	HR above 10
heavy duty	1.5	1.75	2
medium duty	1	1.25	1.5
skip hoist	1	1.25	1.5
heavy duty	1.5	1.75	2
medium duty	1	1.25	1.5
skip hoist	1	1.25	1.5

Laundry washer reversing

Sub-Category	HR < 3	HR Between 3-10	HR above 10
Laundry washer reversing	1	1.25	1.5
Laundry washer reversing	1	1.25	1.5

Laundry tumblers

Sub-Category	HR < 3	HR Between 3-10	HR above 10
Laundry tumblers	1	1.25	1.5
Laundry tumblers	1	1.25	1.5

Line shafts

Sub-Category	HR < 3	HR Between 3-10	HR above 10
driving processing equipment	1	1.25	1.5
light	0.8	1	1.25
other line shafts	0.8	1	1.25
driving processing equipment	1	1.25	1.5
light	0.8	1	1.25
other line shafts	0.8	1	1.25

Lumber industry

Sub-Category	HR < 3	HR Between 3-10	HR above 10
Barkers-hydraulic-mechanical	1	1.25	1.5
burner conveyor	1	1.25	1.5
chain saw and drag saw	1.5	1.75	2
chain transfer	1.5	1.75	2
craneway transfer	1.5	1.75	2
De-braking drum	1.5	1.75	2
edger feed	1	1.25	1.5
gang feed	1	1.25	1.5
green chain	1	1.25	1.5
live roll	1.5	1.75	2
log deck	1.5	1.75	2
log haul-incline	1.5	1.75	2
log haul-well type	1.5	1.75	2
log turning device	1.5	1.75	2
main log conveyor	1.5	1.75	2
off bearing rolls	1	1.25	1.5
planer feed chains	1	1.25	1.5
planer floor chains	1	1.25	1.5
planer tilting hoist	1	1.25	1.5
Re-saw merry-go-round conveyor	1	1.25	1.5
roll cases	1.5	1.75	2
slab conveyor	1.5	1.75	2
small waste conveyor-belt	0.8	1	1.25
small waste conveyor-chain	1	1.25	1.5
starting table	1	1.25	1.5
tipple hoist conveyor	1	1.25	1.5
tipple hoist drive	1	1.25	1.5
transfer conveyor	1	1.25	1.5
tray drive	1	1.25	1.5
trimmer feed	1	1.25	1.5
waste conveyor	1	1.25	1.5
Barkers-hydraulic-mechanical	1	1.25	1.5
burner conveyor	1	1.25	1.5
chain saw and drag saw	1.5	1.75	2
chain transfer	1.5	1.75	2
craneway transfer	1.5	1.75	2
De-braking drum	1.5	1.75	2
edger feed	1	1.25	1.5
gang feed	1	1.25	1.5
green chain	1	1.25	1.5
live roll	1.5	1.75	2
log deck	1.5	1.75	2
log haul-incline	1.5	1.75	2
log haul-well type	1.5	1.75	2
log turning device	1.5	1.75	2
main log conveyor	1.5	1.75	2
off bearing rolls	1	1.25	1.5
planer feed chains	1	1.25	1.5
planer floor chains	1	1.25	1.5
planer tilting hoist	1	1.25	1.5
Re-saw merry-go-round conveyor	1	1.25	1.5
roll cases	1.5	1.75	2
slab conveyor	1.5	1.75	2
small waste conveyor-belt	0.8	1	1.25
small waste conveyor-chain	1	1.25	1.5
starting table	1	1.25	1.5
tipple hoist conveyor	1	1.25	1.5
tipple hoist drive	1	1.25	1.5
transfer conveyor	1	1.25	1.5
tray drive	1	1.25	1.5
trimmer feed	1	1.25	1.5
waste conveyor	1	1.25	1.5

Machine tools

Sub-Category	HR < 3	HR Between 3-10	HR above 10
bending roll	1	1.25	1.5
punching press-gear driven	1.5	1.75	2
notching press-belt driven	*	*	*
plate planers	1.5	1.75	2
tapping machine	1.5	1.75	2
other machine tools main drives	1	1.25	1.5
other machine tools auxillary drives	0.8	1	1.25
bending roll	1	1.25	1.5
punching press-gear driven	1.5	1.75	2
notching press-belt driven	*	*	*
plate planers	1.5	1.75	2
tapping machine	1.5	1.75	2
other machine tools main drives	1	1.25	1.5
other machine tools auxillary drives	0.8	1	1.25

Metal mills

Sub-Category	HR < 3	HR Between 3-10	HR above 10
draw bench carriage and main drive	1	1.25	1.5
pinch,dryer and scrubber	1	1.25	1.5
Rolls-reversing	*	*	*
slitters	1	1.25	1.5
table conveyors non reversing- group drives	1.5	1.75	2
table conveyors non reversing- individual drives	1.5	1.75	2
reversing	*	*	*
wire drawing and flattening machine	1	1.25	1.5
wire winding machine	1	1.25	1.5
draw bench carriage and main drive	1	1.25	1.5
pinch,dryer and scrubber	1	1.25	1.5
Rolls-reversing	*	*	*
slitters	1	1.25	1.5
table conveyors non reversing- group drives	1.5	1.75	2
table conveyors non reversing- individual drives	1.5	1.75	2
reversing	*	*	*
wire drawing and flattening machine	1	1.25	1.5
wire winding machine	1	1.25	1.5

Mills-rotary type

Sub-Category	HR < 3	HR Between 3-10	HR above 10
ball	1	1.25	1.5
cement klins	1	1.25	1.5
dryers and coolers	1	1.25	1.5
Kilns-other than cement	1	1.25	1.5
pebble	*	*	*
Rod-plain	1	1.25	1.5
Rod-wedge bar	1	1.25	1.5
tumbling barrels	1.5	1.75	2
ball	1	1.25	1.5
cement klins	1	1.25	1.5
dryers and coolers	1	1.25	1.5
Kilns-other than cement	1	1.25	1.5
pebble	*	*	*
Rod-plain	1	1.25	1.5
Rod-wedge bar	1	1.25	1.5
tumbling barrels	1.5	1.75	2

Mixer

Sub-Category	HR < 3	HR Between 3-10	HR above 10
concrete mixer-continuous	1	1.25	1.5
concrete mixers-intermittent	1	1.25	1.5
constant density	0.8	1	1.25
variable density	1	1.25	1.5
concrete mixer-continuous	1	1.25	1.5
concrete mixers-intermittent	1	1.25	1.5
constant density	0.8	1	1.25
variable density	1	1.25	1.5

Oil industry

Sub-Category	HR < 3	HR Between 3-10	HR above 10
chillers	1	1.25	1.5
oil well pumping	*	*	*
paraffin filter press	1	1.25	1.5
rotary klins	1	1.25	1.5
chillers	1	1.25	1.5
oil well pumping	*	*	*
paraffin filter press	1	1.25	1.5
rotary klins	1	1.25	1.5

Paper mills

Sub-Category	HR < 3	HR Between 3-10	HR above 10
agitators (mixers)	1	1.25	1.5
barker auxillaries-hydraulic	1	1.25	1.5
Barker-mechanical	1.5	1.75	2
Barker-drum	1.5	1.75	2
beater and pulper	1	1.25	1.5
bleacher	0.8	1	1.25
calenders	1	1.25	1.5
Calenders-super	1.5	1.75	2
converting machine,except cutters-platers	1	1.25	1.5
conveyors	0.8	1	1.25
couch	1.5	1.75	2
Cutters-platers	1.5	1.75	2
cylinders	1	1.25	1.5
dryers	1	1.25	1.5
felt stretcher	1	1.25	1.5
felt whipper	1.5	1.75	2
jordans	1	1.25	1.5
log haul	1.5	1.75	2
presses	1	1.25	1.5
pulp machine reel	1	1.25	1.5
stock chest	1	1.25	1.5
suction roll	1	1.25	1.5
washers and thickners	1	1.25	1.5
winders	1	1.25	1.5
agitators (mixers)	1	1.25	1.5
barker auxillaries-hydraulic	1	1.25	1.5
Barker-mechanical	1.5	1.75	2
Barker-drum	1.5	1.75	2
beater and pulper	1	1.25	1.5
bleacher	0.8	1	1.25
calenders	1	1.25	1.5
Calenders-super	1.5	1.75	2
converting machine,except cutters-platers	1	1.25	1.5
conveyors	0.8	1	1.25
couch	1.5	1.75	2
Cutters-platers	1.5	1.75	2
cylinders	1	1.25	1.5
dryers	1	1.25	1.5
felt stretcher	1	1.25	1.5
felt whipper	1.5	1.75	2
jordans	1	1.25	1.5
log haul	1.5	1.75	2
presses	1	1.25	1.5
pulp machine reel	1	1.25	1.5
stock chest	1	1.25	1.5
suction roll	1	1.25	1.5
washers and thickners	1	1.25	1.5
winders	1	1.25	1.5

Printing presses and pullers

Sub-Category	HR < 3	HR Between 3-10	HR above 10
barge haul	1.5	1.75	2
barge haul	1.5	1.75	2

Pumps

Sub-Category	HR < 3	HR Between 3-10	HR above 10
centrifugal	0.8	1	1.25
proportioning	1	1.25	1.5
Reciprocating-single acting,3 or more cylinders	1	1.25	1.5
Reciprocating-double acting,2 or more cylinders	1	1.25	1.5
Reciprocating-single acting,1 or 2 cylinders	*	*	*
Reciprocating-double acting,single cylinder	*	*	*
Rotary-gear type	0.8	1	1.25
Rotary-lobe,vane	0.8	1	1.25
centrifugal	0.8	1	1.25
proportioning	1	1.25	1.5
Reciprocating-single acting,3 or more cylinders	1	1.25	1.5
Reciprocating-double acting,2 or more cylinders	1	1.25	1.5
Reciprocating-single acting,1 or 2 cylinders	*	*	*
Reciprocating-double acting,single cylinder	*	*	*
Rotary-gear type	0.8	1	1.25
Rotary-lobe,vane	0.8	1	1.25

Rubber and plastic industries

Sub-Category	HR < 3	HR Between 3-10	HR above 10
crackers	1.5	1.75	2
laboratory equipment	1	1.25	1.5
mixing mills	1.5	1.75	2
refiners	1	1.25	1.5
rubber calenders	1	1.25	1.5
Rubber mill-2 on line	1	1.25	1.5
Rubber mill-3 on line	0.8	1	1.25
sheeter	1	1.25	1.5
tyre building machines	*	*	*
tyre and tube press openers	*	*	*
tubers and strainers	1	1.25	1.5
warming mills	1	1.25	1.5
crackers	1.5	1.75	2
laboratory equipment	1	1.25	1.5
mixing mills	1.5	1.75	2
refiners	1	1.25	1.5
rubber calenders	1	1.25	1.5
Rubber mill-2 on line	1	1.25	1.5
Rubber mill-3 on line	0.8	1	1.25
sheeter	1	1.25	1.5
tyre building machines	*	*	*
tyre and tube press openers	*	*	*
tubers and strainers	1	1.25	1.5
warming mills	1	1.25	1.5

Sand mullers

Sub-Category	HR < 3	HR Between 3-10	HR above 10
Sand mullers	1	1.25	1.5
Sand mullers	1	1.25	1.5

Sewage disposal equipment

Sub-Category	HR < 3	HR Between 3-10	HR above 10
bar screens	0.8	1	1.25
chemical feeders	0.8	1	1.25
collectors	0.8	1	1.25
dewatering screws	1	1.25	1.5
scum breakers	1	1.25	1.5
slow or rapid mixtures	1	1.25	1.5
thickners	1	1.25	1.5
vaccum filters	1	1.25	1.5
bar screens	0.8	1	1.25
chemical feeders	0.8	1	1.25
collectors	0.8	1	1.25
dewatering screws	1	1.25	1.5
scum breakers	1	1.25	1.5
slow or rapid mixtures	1	1.25	1.5
thickners	1	1.25	1.5
vaccum filters	1	1.25	1.5

Screens

Sub-Category	HR < 3	HR Between 3-10	HR above 10
air washing	0.8	1	1.25
rotary stone or gravel	1	1.25	1.5
travelling water intake	0.8	1	1.25
air washing	0.8	1	1.25
rotary stone or gravel	1	1.25	1.5
travelling water intake	0.8	1	1.25

Slab pushers

Sub-Category	HR < 3	HR Between 3-10	HR above 10
Slab pushers	1	1.25	1.5
Slab pushers	1	1.25	1.5

Steering gear

Sub-Category	HR < 3	HR Between 3-10	HR above 10
Steering gear	*	*	*
Steering gear	*	*	*

Stockers

Sub-Category	HR < 3	HR Between 3-10	HR above 10
Stockers	0.8	1	1.25
Stockers	0.8	1	1.25

Sugar industry

Sub-Category	HR < 3	HR Between 3-10	HR above 10
Cane Knives	1	1.25	1.5
crushers	1	1.25	1.5
mills	1	1.25	1.5
Cane Knives	1	1.25	1.5
crushers	1	1.25	1.5
mills	1	1.25	1.5

Textile industry

Sub-Category	HR < 3	HR Between 3-10	HR above 10
batchers	1	1.25	1.5
calenders	1	1.25	1.5
cards	1	1.25	1.5
dry cans	1	1.25	1.5
dryers	1	1.25	1.5
dyeing machinery	1	1.25	1.5
knitting machinery	*	*	*
looms	1	1.25	1.5
mangles	1	1.25	1.5
nappers	1	1.25	1.5
pads	1	1.25	1.5
range drives	*	*	*
slashers	1	1.25	1.5
soapers	1	1.25	1.5
spinners	1	1.25	1.5
tenter frames	1	1.25	1.5
washers	1	1.25	1.5
winders	1	1.25	1.5
batchers	1	1.25	1.5
calenders	1	1.25	1.5
cards	1	1.25	1.5
dry cans	1	1.25	1.5
dryers	1	1.25	1.5
dyeing machinery	1	1.25	1.5
knitting machinery	*	*	*
looms	1	1.25	1.5
mangles	1	1.25	1.5
nappers	1	1.25	1.5
pads	1	1.25	1.5
range drives	*	*	*
slashers	1	1.25	1.5
soapers	1	1.25	1.5
spinners	1	1.25	1.5
tenter frames	1	1.25	1.5
washers	1	1.25	1.5
winders	1	1.25	1.5

Windlass

Sub-Category	HR < 3	HR Between 3-10	HR above 10
Windlass	*	*	*
Windlass	*	*	*

Time	Input Speed	Output Speed	Power	Service Factor	Application	Downloaded
11/17/2021 11:24:23 AM	1440	150	10	1	1	-
11/17/2021 11:24:29 AM	1440	150	10	1	1	-
11/17/2021 11:34:20 AM	1440	150	10	1	1	-
11/17/2021 11:35:24 AM	1440	150.00	50	1	1	-
11/17/2021 11:35:42 AM	1440	57.60	50	1	1	-
11/17/2021 11:35:49 AM	1440	57.60	5	1	1	-
11/17/2021 11:35:57 AM	1440	57.60	5	2	1	-
11/17/2021 11:54:47 AM	1440	57.60	5	2	1	-
11/17/2021 12:07:32 PM	1440	288.00	1	1	1	-
11/17/2021 1:03:17 PM	1440	65.16	.12	18	1	-
11/17/2021 3:46:12 PM	1440	150.00	50	1	1	-
11/23/2021 11:27:22 AM	1440	30	5	1.25	solids and liquids	-
11/23/2021 11:27:28 AM	1440	30	1	1.25	solids and liquids	-
11/23/2021 11:27:32 AM	1440	30	1	1	solids and liquids	-
11/23/2021 11:27:40 AM	1440	30	50	1	solids and liquids	-
11/23/2021 11:27:48 AM	1440	10	50	1	solids and liquids	-
11/23/2021 11:27:52 AM	1440	12	50	1	solids and liquids	-
11/23/2021 11:27:58 AM	1440	12	50	10	solids and liquids	-
11/23/2021 11:28:02 AM	1440	12	50	6	solids and liquids	-
11/23/2021 11:28:06 AM	1440	12	50	5	solids and liquids	-
11/23/2021 11:28:10 AM	1440	12	10	5	solids and liquids	-
11/23/2021 11:28:13 AM	1440	12	3	5	solids and liquids	-
11/23/2021 11:28:20 AM	1440	12	3	5	solids and liquids	-
11/23/2021 11:28:37 AM	1440	12	3	3	solids and liquids	-
11/23/2021 11:28:44 AM	1440	12	3	3	solids and liquids	-
11/23/2021 11:36:47 AM	1440	5	3	3	solids and liquids	-
11/23/2021 11:36:52 AM	1440	20	3	3	solids and liquids	-
11/23/2021 11:42:57 AM	1440	20.00	3	3	1	-
11/23/2021 11:44:33 AM	1440	20	3	3	3	-
11/23/2021 11:48:12 AM	1440	20	3	3	3	-
11/23/2021 11:51:32 AM	1440	20.00	3	3	3	-
11/23/2021 11:52:34 AM	1440	20.00	3	3	3	-
11/23/2021 11:55:12 AM	1440	20.00	3	3	3	-
11/23/2021 11:56:29 AM	1440	20.00	3	3	3	-
11/23/2021 11:57:11 AM	1440	20.00	3	3	3	-
11/23/2021 12:00:47 PM	1440	20.00	3	3	3	-
11/23/2021 12:03:42 PM	1440	20.00	3	3	3	-
11/23/2021 12:04:34 PM	1440	20.00	3	3	3	-
11/23/2021 12:07:56 PM	1440	20.00	3	3	3	-
11/23/2021 12:09:17 PM	1440	20.00	3	3	3	-
11/23/2021 12:13:04 PM	1440	2.00	3	3	3	-
11/23/2021 12:13:10 PM	1440	20.00	3	3	3	-
11/23/2021 12:14:28 PM	1440	20.00	3	3	3	-
11/23/2021 12:15:35 PM	1440	20.00	3	3	3	-
11/23/2021 12:16:58 PM	1440	20.00	3	3	3	-
11/23/2021 12:27:27 PM	1440	20.00	3	3	3	-
11/23/2021 12:28:13 PM	1440	20.00	3	3	3	-
11/23/2021 12:33:59 PM	1440	20.00	3	3	3	-
11/23/2021 12:34:49 PM	1440	20.00	3	3	3	-
11/23/2021 12:35:14 PM	1440	2.00	3	3	3	-
11/23/2021 12:35:20 PM	1440	20.00	3	3	3	-
11/23/2021 1:12:52 PM	1440	20.00	3	3	3	K09-100L
12/2/2021 12:31:33 PM	1440	70.00	10	10	10	-
12/2/2021 12:31:43 PM	1440	70.00	3	3	3	-
3/1/2022 10:17:28 AM	1440	144.00		1.25	solids and liquids	-
3/1/2022 10:19:19 AM	1440	144.00		1	centrifugal	K06-71
3/1/2022 10:19:19 AM	1440	144.00		1	centrifugal	K06-71
3/1/2022 10:23:08 AM	1440	144.00		1.5	lobe	K06-71
3/1/2022 10:23:08 AM	1440	144.00		1.5	lobe	K06-71
3/1/2022 10:24:32 AM	1440	144.00		1.25	pure liquids	K06-71
3/1/2022 10:24:32 AM	1440	144.00		1.25	pure liquids	K06-71
3/1/2022 10:25:15 AM	1440	144.00		1.25	solids and liquids	K06-71
3/1/2022 10:26:53 AM	1440	144.00		1.25	solids and liquids	K06-71
3/1/2022 10:26:53 AM	1440	144.00		1.25	solids and liquids	K06-71
3/1/2022 10:26:53 AM	1440	144.00		1.25	solids and liquids	K06-71
3/1/2022 10:26:53 AM	1440	144.00		1.25	solids and liquids	K06-71
3/1/2022 10:26:53 AM	1440	144.00		1.25	solids and liquids	K06-71
3/1/2022 10:59:59 AM	1440	144.00		1	solids and liquids	K06-71
3/1/2022 10:59:59 AM	1440	144.00		1	solids and liquids	K06-71

11/17/2021 11:24:23 AM

admin@sgl.com
11/17/2021 11:24:29 AM

admin@sgl.com
11/17/2021 11:34:20 AM

admin@sgl.com
11/17/2021 11:35:24 AM

admin@sgl.com
11/17/2021 11:35:42 AM

admin@sgl.com
11/17/2021 11:35:49 AM

admin@sgl.com
11/17/2021 11:35:57 AM

admin@sgl.com
11/17/2021 11:54:47 AM

admin@sgl.com
11/17/2021 12:07:32 PM

admin@sgl.com
11/17/2021 1:03:17 PM

admin@sgl.com
11/17/2021 3:46:12 PM

admin@sgl.com
11/23/2021 11:27:22 AM

admin@sgl.com
11/23/2021 11:27:28 AM

admin@sgl.com
11/23/2021 11:27:32 AM

admin@sgl.com
11/23/2021 11:27:40 AM

admin@sgl.com
11/23/2021 11:27:48 AM

admin@sgl.com
11/23/2021 11:27:52 AM

admin@sgl.com
11/23/2021 11:27:58 AM

admin@sgl.com
11/23/2021 11:28:02 AM

admin@sgl.com
11/23/2021 11:28:06 AM

admin@sgl.com
11/23/2021 11:28:10 AM

admin@sgl.com
11/23/2021 11:28:13 AM

admin@sgl.com
11/23/2021 11:28:20 AM

admin@sgl.com
11/23/2021 11:28:37 AM

admin@sgl.com
11/23/2021 11:28:44 AM

admin@sgl.com
11/23/2021 11:36:47 AM

admin@sgl.com
11/23/2021 11:36:52 AM

admin@sgl.com
11/23/2021 11:42:57 AM

admin@sgl.com
11/23/2021 11:44:33 AM

admin@sgl.com
11/23/2021 11:48:12 AM

admin@sgl.com
11/23/2021 11:51:32 AM

admin@sgl.com
11/23/2021 11:52:34 AM

admin@sgl.com
11/23/2021 11:55:12 AM

admin@sgl.com
11/23/2021 11:56:29 AM

admin@sgl.com
11/23/2021 11:57:11 AM

admin@sgl.com
11/23/2021 12:00:47 PM

admin@sgl.com
11/23/2021 12:03:42 PM

admin@sgl.com
11/23/2021 12:04:34 PM

admin@sgl.com
11/23/2021 12:07:56 PM

admin@sgl.com
11/23/2021 12:09:17 PM

admin@sgl.com
11/23/2021 12:13:04 PM

admin@sgl.com
11/23/2021 12:13:10 PM

admin@sgl.com
11/23/2021 12:14:28 PM

admin@sgl.com
11/23/2021 12:15:35 PM

admin@sgl.com
11/23/2021 12:16:58 PM

admin@sgl.com
11/23/2021 12:27:27 PM

admin@sgl.com
11/23/2021 12:28:13 PM

admin@sgl.com
11/23/2021 12:33:59 PM

admin@sgl.com
11/23/2021 12:34:49 PM

admin@sgl.com
11/23/2021 12:35:14 PM

admin@sgl.com
11/23/2021 12:35:20 PM

admin@sgl.com
11/23/2021 1:12:52 PM

admin@sgl.com
12/2/2021 12:31:33 PM

admin@sgl.com
12/2/2021 12:31:43 PM

admin@sgl.com
3/1/2022 10:17:28 AM

admin@sgl.com
3/1/2022 10:19:19 AM

admin@sgl.com
3/1/2022 10:19:19 AM

admin@sgl.com
3/1/2022 10:23:08 AM

admin@sgl.com
3/1/2022 10:23:08 AM

admin@sgl.com
3/1/2022 10:24:32 AM

admin@sgl.com
3/1/2022 10:24:32 AM

admin@sgl.com
3/1/2022 10:25:15 AM

admin@sgl.com
3/1/2022 10:26:53 AM

admin@sgl.com
3/1/2022 10:26:53 AM

admin@sgl.com
3/1/2022 10:26:53 AM

admin@sgl.com
3/1/2022 10:26:53 AM

admin@sgl.com
3/1/2022 10:26:53 AM

admin@sgl.com
3/1/2022 10:59:59 AM

admin@sgl.com
3/1/2022 10:59:59 AM

admin@sgl.com

Product Selection Tool

Heli Bevel Geared Motor

Parallel-Helical Gearbox

Gear Unit Data

Motor Data

Design Features

Product List
